QGDW 12483.5-2025 变电站集中监控系统 第5部分：功能应用VIP免费

ICS 29.240 CCS F 20 备案号：68965-2019 国家电网有限公司企业标准Q/GDW 12483.5—2025 变电站集中监控系统第 5 部分：功能应用 Substation centralized monitoring and control system — Part 5: Function application 2025-11-30发布 2025-11-30实施 国家电网有限公司 发 布 附件35Q/GDW 12483.5—2025 I 目 次前言··································································································································································· II 1 范围······························································································································································1 2 规范性引用文件 ··········································································································································1 3 术语和定义··················································································································································1 4 功能应用架构 ··············································································································································1 5 应用功能······················································································································································4 6 系统建设过渡阶段兼容性功能················································································································· 30 7 安全防护···················································································································································· 33 8 功能应用性能指标 ···································································································································· 34 附录 A （资料性） 与调度主站保信、录波数据交互 ················································································· 36 附录 B （资料性） 操作指令示例 ················································································································ 52 附录 C （资料性） 基本报表示例 ················································································································ 53 附录 D （规范性） 电气操作防误服务接口定义························································································· 54 附录 E （规范性） 顺控调用模式交互文件格式························································································· 64 附录 F （资料性） 监控日志格式示例········································································································· 66 附录 G （规范性） 存量辅助设备监控系统导出 CIM/E 模型格式····························································· 67 附录 H （资料性） API 接口调用················································································································· 69 附录 I （资料性） 服务化接口调用············································································································· 76 附录 J （资料性） 集控系统监控月报表模板····························································································· 83 附录 K （资料性） 功能应用间交互及数据发布共享定义·········································································· 86 附录 L （资料性） 事件化推理 ···················································································································· 96 编制说明························································································································································ 101 Q/GDW 12483.5—2025 II 前 言 本文件依据 GB/T 1.1—2020《标准化工作导则 第 1 部分：标准化文件的结构和起草规则》的要求，按照《国家电网有限公司技术标准管理办法》的规定起草。 本文件是 Q/GDW 12483《变电站集中监控系统》的第 5 部分。Q/GDW 12483 发布了以下部分： ——第 1 部分：总则； ——第 2 部分：设计规范； ——第 3 部分：数据规范； ——第 4 部分：基础平台； ——第 5 部分：功能应用； ——第 6 部分：人机界面； ——第 7 部分：检测规范； ——第 9 部分：电网资源业务中台交互。 本文件由国家电网有限公司设备管理部提出并解释。 本文件由国家电网有限公司科技创新部归口。 本文件起草单位：国网福建省电力有限公司、中国电力科学研究院有限公司、国电南瑞科技股份有限公司、国网河北省电力有限公司、国网江苏省电力有限公司、国网甘肃省电力公司、国网浙江省电力有限公司、国网四川省电力公司、许继电气股份有限公司、安徽南瑞继远电网技术有限公司、北京科东电力控制系统有限责任公司、南京南瑞继保电气有限公司、福建和盛高科技产业有限公司、北京四方继保工程技术有限公司、国电南京自动化股份有限公司、积成电子股份有限公司。 本文件主要起草人：卢彤、李岩、孙杨、林匹、李劲松、胡浔惠、梁李凡、蒋肇杰、杨世仁、李博、季剑、秦剑华、赵俊蕾、吴虓、张炜、俞一峰、袁啸峰、姚楠、何锐、朱宇、肖文妍、朱轶伦、盛振明、马洁、余静、许花、刘超、樊磊、刘家国、邰纯亮、茹东武、陈志刚、李洪峰、陈璐、夏慧、郝旭亮、李晓燕、张高峰、魏力、王海东、黄浩然、赵阳、季潇、李丽、武二克、钱进、王位杰、卢闽、张磊、张合宝。 本文件为首次发布。 本文件在执行过程中的意见或建议反馈至国家电网有限公司科技创新部。 Q/GDW 12483.5—2025 1 变电站集中监控系统 第 5 部分：功能应用 1 范围 本文件规定了变电站集中监控系统的功能应用要求，包括运行监视、操作与控制、监控助手、业务管理、远程智能巡视等，以及兼容采用非高可靠二次系统技术变电站的功能。 本文件适用于 35 kV～500 kV 变电站接入的变电站集中监控系统建设，可供其他电压等级变电站和集控系统建设参考。 2 规范性引用文件 下列文件中的内容通过文中的规范性引用而构成本文件必不可少的条款。其中，注日期的引用文件，仅该日期对应的版本适用于本文件；不注日期的引用文件，其最新版本（包括所有的修改单）适用于本文件。 GB 18030 信息技术 中文编码字符集 GB 50440 城市消防远程监控系统技术规范 DL/T 2140 无人值班变电站消防远程集中监控系统技术 Q/GDW 273 继电保护故障信息处理系统技术规范 Q/GDW 11914 电力监控系统网络安全监测装置技术规范 Q/GDW 12483.3—2025 变电站集中监控系统 第 3 部分：数据规范 Q/GDW 12483.4—2025 变电站集中监控系统 第 4 部分：基础平台 Q/GDW 12483.6—2025 变电站集中监控系统 第 6 部分：人机界面 Q/GDW 12483.9—2025 变电站集中监控系统 第 9 部分：电网资源业务中台交互 Q/GDW 12587.3—2025 高可靠变电站二次系统 通用技术规范 第 3 部分：变电站设备信息模型 Q/GDW 12587.5—2025 高可靠变电站二次系统 通用技术规范 第 5 部分：二次设备安全防护 Q/GDW 12587.7 高可靠变电站二次系统 通用技术规范 第 7 部分：电气操作防误 Q/GDW 12587.9 高可靠变电站二次系统 通用技术规范 第 9 部分：信号自动联调 Q/GDW 12588.2—2025 高可靠变电站二次系统 装置技术规范 第 2 部分：多功能测控装置 Q/GDW 12589.4—2025 高可靠变电站二次系统 站控系统技术规范 第 4 部分：数据通信网关机 3 术语和定义 下列术语和定义适用于本文件。 3.1 事件化告警 events for information monitoring 依据事件规则经过推理分...
